VX30/VX50 Gen3/ECO50 Vacuum Excavators Controls 20-21
(4) Boom Gate Open/Close
Press top . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .close gate
Press bottom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .open gate
4
