"3072ES / 3772ES / 3772ES HD" Service & Parts Manual October 2008
Page 4-19
EZ-Cal DIAGNOSTICS Menu continued
continued…
Current status of enable trigger - platform controller
Status of Lift/Drive selector switch
Indicates % of stroke from center in real time. Direction not indicated here.
Status of Forward micro-switch Forward stroke of the joystick
Status of Reverse micro-switch Reverse stroke of the joystick
Status of Left Steer switch
Status of Right Steer switch
Status of rear wheel solenoids activation. Activated in high speed or elevated drive
Not used
Status of Up switch from lower control station
Status of Down switch from lower control station
Not used
Not used
Not used
12V supply from Motor Controller. ON= Voltage, OFF= no voltage
Base selected, ON= selector on Base position - unit operating from base controls
Up selected from base controls, ON= Up activated
Platform Selected. ON= selector in platform position. Operate from platform controls
Platform Down limit switch. ON= platform down, OFF= platform elevated
Down selected from base controls, ON= Down activated
Not used
Outrigger retracted L/R. ON= retracted, OFF= extended beyond 1/2"
Outrigger retracted R/R. ON= retracted, OFF= extended beyond 1/2"
Outrigger retracted R/F. ON= retracted, OFF= extended beyond 1/2"
Outrigger retracted L/F. ON= retracted, OFF= extended beyond 1/2"
O/R pressure switches.
ON= weight on all 4 outrigger legs, OFF= one or more legs up
Not used
Current state of angle transducer (overload option only)
Current state of pressure transducer (overload option only)
2B PLATFORM
2C GROUND
2D INPUTS
READOUT = Plug and Pin
example:
P7-1 = Plug 7 Pin1
refer to schematic
2E ANALOGS
2B-1
2B-2
2B-3
2B-4
2B-5
2B-6
2B-7
2B-8
2B-9
2C-1
2C-2
2C-3
2C-4
2C-5
2D-1
2D-2
2D-3
2D-4
2D-5
2D-6
2D-7
2D-8
2D-9
2D-10
2D-11
2E-1
2E-2
Trigger ON/OFF
DLD
Joystick
FWD/DOWN OFF/ON
REV/UP OFF/ON
LEFT OFF/ON
RIGHT OFF/ON
Posi-track Y/N
EMSp OFF/ON
UP OFF/ON
DOWN OFF/ON
OUT OFF/ON
IN OFF/ON
EMSg OFF/ON
P7-1
P7-2
P7-3
P7-4
P7-5
P7-7
P7-6 & P7-8 – P7-15
P15-1
P15-2
P15-3
P15-4
P15-5 – P15-8
P15-9
P8-2
P8-6
SELECTION I D READOUT
EXPLAINATION
