October 2008 "3072ES / 3772ES / 3772ES HD" Service & Parts Manual
Page 4-20
EZ-Cal
DIAGNOSTICS
Menu
continued
SELECTION I D READOUT
EXPLAINATION
2F OUTPUTS Numbers not listed but displayed by EZ-Cal
are not used.
READOUT = Plug# and Pin#
example:
P7-1 = Plug 7-Pin1
refer to schematic
2G MONITOR
2H LOG
2F-1
2F-2
2F-3
2F-4
2F-5
2F-6
2F-7
2F-8
2F-9
2F-10
2F-11
2F-12
2F-13
2F-14
2F-15
2F-16
2F-17
2F-18
2F-19
2F-20
2F-21
2F-22
2F-23
2G-1
2G-2
2G-3
2H-1
2H-2
2H-3
P4-10
P4-12
P4-14
P5-1
P5-2
P5-3
P5-4
P5-5
P5-6
P5-7
P5-8
P5-9
P5-10
P5-11
P5-12
P6-1
P6-2
P6-3
P6-4
P6-5
P6-6
P6-7
P6-10
MAIN
SAFE
SAFE TOP
Cal Date
Software
Powered
Rear wheel bypass valves. ON= valves powered - rear wheels in bypass
Line Contactor signal B+. ON= Contactor closed
Down Valve/s signal B+. ON= down valve activated
Lift Valve Signal B+. ON= lift valve activated
Steer right signal B+. ON= valve activated
Steer Left signal B+. ON= valve activated
Drive FWD signal B+. ON= valve activated
Drive Rev signal B+. ON= valve activated
Alarm signal B+. ON= alarm activated
High Torque signal B+. ON= valve activated
High Speed signal B+. ON= valve activated
Hour Meter signal B+. ON= Meter activated
Outrigger Extend signal B+. ON= valve activated (sends oil to O/R legs)
Outrigger Retract signal B+. ON= valve activated (sends oil to O/R legs)
Power supply to Limit Switch. Should be ON when system is powered up
Retract R/F outrigger. ON= valve activated.
Retract L/F outrigger. ON= valve activated.
Retract R/R outrigger. ON= valve activated.
Retract L/R outrigger. ON= valve activated.
Extend R/F outrigger. ON= valve activated
Extend L/F outrigger. ON= valve activated
Extend R/R outrigger. ON= valve activated
Extend L/R outrigger. ON= valve activated
Refers to valve output,
Refers to P4-12 – P4-15 outputs
embedded circuit protection, failure here = internal failure
Date of Load Sense calibration (Euro option only)
Should read 'V22.3' This is MEC specific software.
Accumulated time GP400 powered up (red LED on)
