MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
438. PCIE0_IMBASEBAR0: Internal Memory Base address for BAR0 Space of PCIe Controller (offset: 0x0018)
Internal Memory Base address for BAR0
This register is used when CHIP behaves as a
PCI Express RC.
The actual internal memory address being
accessed by an external PCI host can be
obtained from the following formula:
CHIP address begin accessed = (PCI Address –
BAR0) + IMBASEBAR0.
When writing to this register, the related bit
will take effect when the corresponding bit in
BAR0MSK bit is 1 and BAR0ENB is 1.
439. PCIE0_ID: Vendor and Device ID of PCIe Controller (offset: 0x0030)
440. PCIE0_CLASS: Class Code and Revision ID of PCIe Controller (offset: 0x0034)
441. PCIE_SUBID: Sub Vendor and Device ID of PCIe Controller (offset: 0x0038)
This register is valid when PCIE_RC_MODE = 0. See SYSCFG1 (offset: 0x0014).
442. PCIE0_STATUS: PCIe Status Register (offset: 0x0050)
PCIe LTSSM Link up indicator
This bit will reflect the PCIe link up status.
Users can use this bit to see if any device is
plugged into the slot.
443. DLECR: Datalink Layer Error Counter Register (offset: 0x0060)
Datalink Layer Error Counter
Records how many times a datalink layer error
occurred.
