MEDIATEK Ralink MT7620 - Page 45

PGMT7620_V.1.0_040503
Page 45 of 523
MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
Bits
Description
11:10
Output voltage level
Value
Description
00
0.7 V
10
0.8 V
01
0.75 V
11
0.85 V
9
Reserved
8:4
Output termination adjustment
Value
Description
Value
Description
Value
Description
00000
70
01010
52
10101
41
00001
66
01011
51
10110
40
00010
64
01100
50
10111
39
00011
62
01101
49
11000
38.5
00100
61
01110
48
11001
38
00101
59
01111
47
11010
37.5
00110
58
10000
46
11011
37
00111
56
10001
45
11100
36.5
01000
55
10010
44
11101
36
01001
54
10011
43
11110
35.5
10100
42
11111
35
3:2
Output slew-rate control
Value
Description
00
1.71 V/ns
01
1.12 V/ns
10
0.78 V/ns
11
0.6 V/ns
1:0
Reserved
