MT7620 PROGRAMMING GUIDE
Integrated 802.11n MAC/BBP and 2.4 GHz RF/FEM Router-on-a-Chip
Bits
Type
Name
Description
Initial Value
0
RW
ERBFI
Enable Rx Buffer Full Interrupt
Enables the receive buffer full interrupt, as well
as the data ready (DR) and character time-out
interrupts.
0x0
NOTE:
0: Disable
1: Enable
49. IIR: Interrupt Identification Register (offset: 0x000C)
Bits
Type
Name
Description
Initial Value
31:8
-
-
Reserved
-
7:6
RO
FIFOEN
FIFOs Enabled
These bits reflect the FIFO enable bit setting in
the FIFO Control Register.
00: FIFO enable bit is cleared.
11: FIFO enable bit is set.
0x0
5:4
-
-
Reserved
0x0
3:1
RO
INTID
Interrupt Identifier
These bits provide a snapshot of the interrupt
type, and may be used as the offset into an
interrupt vector table.
See NOTE below.
0x0
0
RO
INTPEND
Interrupt Pending
0: An interrupt bit is set and is not masked.
1: No interrupts are pending.
0x1
NOTE:
The interrupt encoding is given below.
ID
Priority
Type
Source
7
Undefined
6
Undefined
5
Undefined
4
Undefined
3
1 (highest)
Receiver Line Status
OE, PE, FE, BI
2
2
Receiver Buffer Full
DR
1
3
Transmitter Buffer Empty
THRE
0
4 (lowest)
Modem Status
DCTS, DDSR, RI, DCD
If more than one category of interrupt is asserted, only the highest priority ID is given.
The line and modem status interrupts are cleared by reading the corresponding status register in the UART
block (LSR (0x001C), MSR (0x0020)). The receive buffer full interrupt is cleared when all of the data is read
from the receive buffer. The transmit buffer empty interrupt is cleared when data is written to the TBR register
(0x0004) in the UART block.
