Operating Instructions - CPC6050 81
Modular Pressure Controller
CPC6050
Measure? <sp>(YES or NO)<cr><lf> Returns YES if instrument is in mea-
sure. NO if otherwise
Meas_Reg ON or OFF Sets the regulation of the pressure
across the Measure/Control solenoid,
see Section 6.4.3.10 Detection Flags.
Meas_Reg? <sp>(YES or NO)<cr><lf> Returns whether measure regulation
is enabled
Mode MEASURE, CONTROL, VENT Sets the operation mode
Mode? <sp>XXXXXX<cr><lf> Returns the operation mode
Netmask nnn.nnn.nnn.nnn Sets the Ethernet network mask
Netmask? <sp>nnn.nnn.nnn.nnn<cr><lf> Gets the Ethernet network mask
OSversion? <sp>n.n<cr><lf> Returns the operating system version
Outform 1 to 7 – see table in Section 7.7.3 Sets the output format
Outform? <sp>X<cr><lf> Returns the output format – see table
in Section 7.7.3
Peakmax? <sp>n.nnnnnE+nn<cr><lf> Returns the maximum pressure since
peakreset was sent
Peakmin? <sp>n.nnnnnE+nn<cr><lf> Returns the minimum pressure since
peakreset was sent
Peakreset None Resets the peak values.
Port nnnnnn Sets the Ethernet port of the instru-
ment
Port? <sp>nnnnn<cr><lf> Returns the Ethernet port of the in-
strument
Precision ON or OFF Sets the precision control mode,
which sets the control behavior, stable
window, stable delay, and rate set-
point
Precision? <sp>(YES or NO)<cr><lf> Returns the status of the precision
mode
Ptype Absolute or Gauge Sets the instrument pressure type –
emulation only works if the optional
barometric transducer is installed. If
no barometer is present, standard
atmosphere is used for the barometric
reading when in emulation mode.
Ptype? <sp>CCCCC<cr><lf> Returns “Absolute” or “Gauge” for the
pressure type in native mode and
“Absolute Emulated” or “Gauge Emu-
lated” for the emulated pressure types
Purge Value inside upper and lower limits,
never in the vacuum region
Start purge sequence with DUT pres-
sure as the setpoint. Only applicable
with option PURGE enabled
