2. Installation

2.1. Unpack and verify the shipment

Check for any obvious damage to the carton or its contents. If possible, take a

picture of any damaged part.

Figure 2-1 Unpacking Carriage, Seat, and Rails

x 1

Carriage

x 1

Seat

x 1

Rack

x 2

Rails + Racks

Box 1: Carriage

Box 2: Seat

Box 3 & 4: Rails and Racks
