Merits Pilot - Dismantling Components; Figure 4-1 Dismantling Sequence

To Next Page

To Previous Page

4-1

4. Dismantling Components

The stairlift must only be serviced and maintained by trained personnel. Before

working on the stairlift ensure that power is switched off and unplug the charger

from the household wall outlet. Follow the dismantling procedure in Figure 4-1 to

replace the components.

Figure 4-1 Dismantling sequence

DISMANTLING

SEQUENCE

ROCKER

SWITCH (4.1.1)

ARMREST

SWITCH (4.1.2)

EMERGENCY STOP

BUTTON (4.1.3)

SEAT

(4.2)

SWIVEL SWITCH

(4.2.1)

BATTERIES

(4.4.1)

FOOTREST

(4.3)

CONTROL PCB

(4.4.2)

MOTOR

BRUSHES (4.4.3)

FUSE

(4.4.4)

CHARGING PINS

(4.4.5)

COVERS

(4.4)

OBSTACLE

SWITCHES (4.4.6)

POWER SWITCH

(4.4.7)

IR PCB

(4.4.8)

TOP RAIL

ACCESSORIES (4.5)

STATUS DISPLAY

PCB (4.4.9)

KEY SWITCH

(4.4.10)

CARRIAGE

(4.6)

ROLLERS

(4.6.1)

LIMIT SWITCHES

(4.6.2)

RAIL

(4.7)
