1-1
1. Introduction
1.1.Intended Use
1.2.How to Use Installation and Service Manual
Introduction
Installation
Testing
Dismantling Components
Maintenance
Troubleshooting
All section titles, subject subtitles and illustration are listed in the Table of Contents.
Note
This manual specifically instruction for service engineers and distributors
only. This is not a manual for user use.
1.3.Safety Rules
As you read the manual, please pay attention to all of following:
Fire Hazard-Do not use an improper voltage source. Verify the rated voltage
matches the voltage of the charger before applying power.
Electrical Shock Hazard -Do not remove or open the cover during operation.
Disconnect the power cord from the electrical outlet before cleaning or
servicing.
The Stairlift basically consists of four parts: the carriage, the footrest, the seat, and
the rail. The stairlift is powered by the rechargeable batteries inside the carriage.
There are safety sensors on upper and lower covers and bottom of footrest. These
sensors will stop the unit if any obstruction is detected on the rail or stairway. The
footrest, the armrests and the seat can be folded up when not in use to allow more
space on the stairway. Pull the swivel handle up to unlock the seat when you reach
the top of the stairs. This will allow you to get into or out of the seat at a convenient
position. The rail has two charging points at the top and bottom. The batteries can be
recharged automatically when the unit stops at these positions.
The Stair Lift System is a powered patient transport, also commonly known as a Stairway
Chairlift, or Stairlift. It is a motorized device intended for medical purposes to assist
transfers of patients, or mobility-impaired persons, up and down flights of stairs. This
stairlift can only be used on straight staircases inclined between 25°~55°. It is designed
to carry one person at a time and the maximum weight capacity is 158kg (350lbs). Any
other uses which this stairlift does not intend for may cause serious injury or damage to
personal property.
This manual provides instruction for installation and servicing of the stairlift. This
manual includes whole sections in the following:
