4-5

4.3. FootrestRemoval

4.3.1. Top Cover Removal

i. Loosen four screws from the footrest.

ii. Remove the top cover.

Figure 4-7 Top cover removal

4.3.2. Footrest and Seat Post Removal

i. Disconnect the footrest cable.

ii. Loosen three bolts from the carriage side plate.

Figure 4-8 Footrest and seat post removal
