7. Tool Kit

The service tools are shown in Figure 7-1 and list below.

Figure 7-1 Tool Kit of Service

Table 7-1 Tool Kit

Item Tool Name

1 Metric Hex L-Key Set

2 External Retaining-Ring Plier

3 Needle-nose Plier

4 Wire Cutter

5 17mm Combination Wrench

6 13mm Combination Wrench

7 10mm Combination Wrench

8 Slotted-head Screwdriver

9 Philips-head #2 Screwdriver

10 Philips-head #0 Screwdriver

11 Tape Rule

12 Multimeter
