Figure 2-23 Rocker switch wiring for different handing

2.10.2. Change Handing of Armrest (if required)

The armrest safety switch must be installed on the downstairs side. Change the

armrest safety switch if required. Unscrew the four screws under the armrests.

Open the armrest bottom covers. Change the plugs and switch to the mirror side.

Close the armrest covers and fasten the screws.

Figure 2-24 Armrest bottom cover screws

Right-Hand

Left-Hand

Black

Blue

Black

Blue
