2.10.6. Secure Seat on Seat Post

Install the pin and the nylon washer under the seat to secure seat on seat post.

Bend one end of pin to lock it.

Figure 2-29 Install pin and nylon washer

2.11. Install Covers

2.11.1. Install Seat Post Cover

Assemble the cover with four screws.

Figure 2-30 Install seat post cover
