3. Testing
The stairlift must be tested to ensure that it is operating correctly after installation
or service.
3.1. Remote Control Testing
Verify the moving direction of stairlift by pressing the up or down button on the
remote control. Check the wiring of motor if the direction is reversed.
3.2. Seat Testing
3.2.1. Rocker Switch Direction
Sit on the seat and press the rocker switch on the armrest. Check the moving
direction of the stairlift. Check the wiring of rocker switch if the direction is
reversed. Refer to Figure 2-23 for correct wiring.Check the status display and
follow the corrective action if there is any problem.
3.2.2. Swivel Handle
Sit on the seat and lift the swivel handle. Check the locking function at different
angle. Press the rocker switch on the armrest at all angles. The stairlift can only
move at riding position. The status display indicates at the other position.
Check the switch under the seat if there is any problem.
Figure 3-1 Seat swivel
