4-8

4.3.6. Footrest Parts Assembly

i. Insert the hook of spring in the slot. Rotate the spring to fit in the

footplate.

Figure 4-13 Torsion spring assembly

ii. Push the shaft through the footplate and the spring. Use a cable tie to fix

the footrest cable.

Figure 4-14 Footplate shaft assembly
