2-21

2.14. Assemble Rail End Covers

Insert the wires into the cavity of rail carefully. Assemble the end covers on top and

bottom of rail.

Figure 2-35 Assemble rail end cover

2.15. Mount Charger and Remote Control Holder

Mount the charger on the wall at upstairs or downstairs. Mount remote control

holder on the wall at both upstairs and downstairs.

2.16. Check Installation and Lubricate

Verify that all mechanical components and electrical connections are properly

installed. Use the tube of grease to lubricate the rack teeth.
