© Microhard Systems Inc. 110
4.0 WebUI Configuration
Port
Values (Port #)
Active Timeout
Values (seconds)
Enter the port number on the IPn3G in which to listen for incoming Modbus
messages.
502
Define the active timeout in seconds.
300
Slave ID
Each Modbus slave device must have a unique address, or Slave ID. Enter
this value here as required by the Modbus Host System.
Values (value)
1
Coils Address Offset
Enter the Coils Address offset as required by the Master.
Values (value)
0
Input Address Offset
Enter the Input Address offset as required by the Master.
Values (value)
0
Register Address Offset
Enter the Register Address offset as required by the Master.
Values (value)
0
Master IP Filter Set
It is possible to only accept connections from specific Modbus Master IP’s,
to use this feature enable the Master IP Filter and specify the IP Addresses
in the fields provided.
Values (selection)
Disable / Enable
