Microhard Systems IPN3G - RF Performance

© Microhard Systems Inc. 12
1.0 Overview
1.3 IPn3Gb RF Performance
Frequency Range Min. (MHz) Max. (MHz) Remarks
GSM 850
Uplink 824 849 Module transmit
Downlink 869 894 Module receive
E-GSM 900
Uplink 880 915 Module transmit
Downlink 925 960 Module receive
DCS 1800
Uplink 1710 1785 Module transmit
Downlink 1805 1880 Module receive
PCS1900
Uplink 1850 1910 Module transmit
Downlink 1930 1990 Module receive
UMTS 800 (band VI)
Uplink 830 840 Module transmit
Downlink 875 885 Module receive
UMTS 850 (band V)
Uplink 824 849 Module transmit
Downlink 869 894 Module receive
UMTS 900 (band VIII)
Uplink 880 915 Module transmit
Downlink 925 960 Module receive
UMTS 1700 (band VIII)
Uplink 1710 1755 Module transmit
Downlink 2110 2155 Module receive
UMTS 1900 (band II)
Uplink 1850 1910 Module transmit
Downlink 1930 1990 Module receive
Uplink 1920 1980 Module transmit
UMTS 2100 (band 1)
Downlink 2110 2170 Module receive
Table 1-1: IPn3Gb Operating RF Frequency Bands
Receiver Input Sensitivity Min. (dBm) Typ. (dBm) Max. (dBm) Remarks
GSM 850 / E-GSM 900 -102.0 -110.0 Downlink RF level @ BER Class II < 2.4%
DCS 1800 / PCS 1900 -102.0 -109.0 Downlink RF level @ BER Class II < 2.4%
UMTS 800 (band VI) -106.7 -111.0 Downlink RF level for RMC @ BER < 0.1%
UMTS 850 (band V) -104.7 -112.0 Downlink RF level for RMC @ BER < 0.1%
UMTS 900 (band VIII) -103.7 -111.0 Downlink RF level for RMC @ BER < 0.1%
UMTS 1700 (band VIII) -106.7 -111.0 Downlink RF level for RMC @ BER < 0.1%
UMTS 1900 (band II) -104.7 -111.0 Downlink RF level for RMC @ BER < 0.1%
UMTS 2100 (band 1) -106.7 -111.0 Downlink RF level for RMC @ BER < 0.1%
Condition: 50 Ω source
Table 1-2: IPn3Gb Receiver sensitivity performance
