© Microhard Systems Inc. 77
4.0 WebUI Configuration
Protocol
Select the type of transport protocol used. For example Telnet uses TCP,
SNMP uses UDP, etc.
Values
External Port
Port number of incoming request (from WAN-side).
Values (Port #)
2000
TCP
UDP
all
Rule Name
This is simply a field where a convenient reference or description is added
to the rule. Each Forward must have a unique rule name and can use up to
10 characters.
Values (10 chars)
Forward
Internal Server IP
Enter the IP address of the intended internal (i.e. on LAN side of IPn3G)
server.
Values (IP Address)
192.168.2.1
Internal Port
Target port number of internal server on the LAN IP entered above.
Values (Port #)
3000
Exception Port
Enter a exception port number that will NOT be forwarded to the DMZ
server IP. Usually a configuration or remote management port that is
excluded to retain external control of the IPn3G.
Values (Port #)
none
DMZ Server IP
Enter the IP address of the destination device on the LAN side of the
IPn3G.
Values (IP Address)
192.168.100.100
More Exception Ports
Enter any additional ports that are not to be forwarded, each separated by
a comma.
Values (Port #)
none
If DMZ is enabled and an
exception port for the
WebUI is not specified,
remote management will
not be possible. The
default port for remote
management is TCP 80.
