4.0 WebUI Configuration
Local Setup > Gateway IP Address
Displays the current WAN IP address of the IPn3G, which is the local VPN
Gateway.
Values (IP Address)
Current IP Address
Subnet IP Address
Displays the local subnet used by the IPn3G for local devices, those
connected to the Ethernet Port. To modify the subnet used, visit the
Network Configuration menus.
Values (IP Address)
192.168.0.0
Subnet Mask
Displays the local subnet mask used by the IPn3G for local devices.
Values (IP Address)
255.255.255.0
Remote Setup > Start IP Address
Enter the starting range of IP Addresses that will be assigned to a remote
VPN adapter (such as a remote PC) when a VPN tunnel is created.
Values (IP Address)
192.168.0.201
End IP Address
Enter the end of the range of IP Addresses that will be assigned to a
remote VPN adapter (such as a remote PC) when a VPN tunnel is created.
Values (IP Address)
192.168.0.210
Local Setup > Local Security Gateway Type
Specify the method for identifying incoming L2TP connections. Remote
systems can simply specify the IP address, or it can be configured that the
Server ID must also be known.
Values (selection)
IP Only
IP + Server ID
Server ID
Specify the Server ID if required by the Local Security Gateway Type
above. Usually this is in the format of @name.
Values (characters)
(no default)
Certificate / Private Key
If X.509 CA is chosen as the authentication method for the L2TP server,
then the certificates must be loaded using the Certificate Management
menu located under security. Specify which certificate / private key is being
used with this tunnel here.
Values (characters)
(no default)
IPsec Setup - Refer back to the previous section for information about IPsec parameters.
