4.0 WebUI Configuration
Local Setup > Local Security Gateway Type
The L2TP requires that incoming connections know their IP Address and/or
the Server ID. Select which parameters are used by the L2TP server.
Values (selection)
IP Only
IP + Server ID
Dynamic IP + Server ID
Local Setup > Gateway IP Address
The current WAN IP address is shown here.
Values (IP Address)
Current IP Address
Local Setup > Local ID
If the server ID is required, enter the ID here.
Values (characters)
(no default)
Remote Setup > Remote Security Gateway Type
The L2TP requires that incoming connections know their IP Address and/or
the Server ID. Select which parameters are used by the L2TP server. The
L2TP server must have a static, known IP address to create a tunnel.
Values (selection)
IP Only
IP + Server ID
Remote Setup > Gateway IP Address
Enter the IP address of the L2TP server that is to be connected to.
Values (IP Address)
(no default)
Remote Setup > Server ID
If the server ID is required, enter the ID here.
Values (characters)
(no default)
Remote Setup > Subnet IP Address
Enter the IP Address of the remote network.
Values (IP Address)
(no default)
Remote Setup > Subnet Mask
Enter the subnet mask of the remote network.
Values (IP Address)
(no default)
IPsec Setup - Refer back to the previous sections for information about IPsec
parameters.
