OMNIScanner User Guide
Chapter 1 - Introduction
The Digital Solution for Fiber and Copper
OMNI Scanner is the most advanced hand-held certification and diagnostic
tool for the verification of copper links. The Category 7, 6, 5E (Enhanced),
5 and ISO Class F, E, D, and C tester has an extended frequency range of
300 MHz. OMNI Scanner provides full software compliance with TIA and
ISO/IEC requirements for measurement reporting and analysis (including
Length, Delay, ACR, NEXT, ELFEXT, Return Loss, Resistance, PSNEXT,
PSACR, PSELFEXT and Attenuation). In addition, OMNIScanner mea-
sures Length, Delay, Impedance, and Resistance on coaxial cabling.
OMNI Fiber MM (multimode) and OMNI Fiber SM (single-mode) expand the
tester’s capabilities to certify installed fiber links against TIA and ISO
standards. Fiber cabling can be verified at 850, 1300, 1310, and 1550 nm
wavelengths.
The Graphical User Interface
OMNI Scanner ’s graphical user interface consists of a backlit LCD display,
quick access menus, arrow keys, and descriptive menu options that guide
you through certifying or troubleshooting cabling systems.
OMNIRemote
For test and certification of twisted pair cabling, the OMNI Scanner requires
the OMNI Remote unit at the opposite end of the cabling link under test.
OMNI Scanner communicates with OMNI Remote to obtain status and
perform measurements from both ends of the link.
OMNI Remote is equipped with a speaker to generate tones, and several
colored LEDs to indicate overall test results and status.
