Microtest OMNIScanner2 - OMNIScanner’s Keypad

OMNIScanner User Guide
1 - 4
ADAPTER CONNECTOR
FUNCTION KEYS
ON/OFF BACKLIGHT
AUTOTEST ESCAPE
ALPHANUMERIC ARROW KEYS
KEYS
ENTER
UPPER/LOWER
CASE HELP KEY
SWITCH KEY
AC ADAPTER
USB PORT DB-9 SERIAL MMC CARD
(OMNISCANNER2) CONNECTOR SOCKET (OMNISCANNER2)
OMNIScanner’s Keypad
ON/OFF
When turned on OMNI Scanner will display the project screen.
Backlight
Press the Backlight key to toggle the backlight between its two levels of
brightness. Press and hold the Backlight key to display the CONTRAST
