5 - 1
OMNIScanner User Guide
Chapter 5 - Measurements
Note: The list of tests in the Measurement screen changes depending on
the adapter that is currently attached to OMNIScanner.
Performing Individual Measurements with OMNIScanner
OMNI Scanner allows you to perform tests on twisted pair, fiber optic and
coaxial cabling.
Measuring Twisted Pair Cabling
OMNI Scanner allows you to run various individual tests. The tests are
conveniently grouped into two screens and can be accessed separately with
the alphanumeric keypad.
Press the (Measurements) function key to display the MEASURE-
MENTS screen.
Press the (Page Down) function key to scroll to the second screen
containing MEASUREMENTS.
Press the (Page Up) function key to return to the first screen con-
taining MEASUREMENTS.
