OmniScanner User Guide

D - 2

Cable Pin-Out Signals

The signals for the cable pin-outs are as follows:

DB-9 DB-25 DB-9

Male Female Female

Pin Pin Pin Signal Signal Description

57 5 GND Protective Ground

32 3 TXD Transmitted Data

23 2 RXD Received Data

74 7 RTS Request to Send

85 8 CTS Clear to Send

420 4 DTR DataTerm Ready

66 6 DSR Data Set Ready

18 1 CD Received Line Signal Detector

922 9 RI Ring Indicator
