• Cyclades ( http://www.cyclades.com ) Cyclades-Z Series 16 to 64 port PCI multiport
asynchronous board with maximum of 256 ports (4 cards)
• TCL ( http://www.thetcl.com ) DataBooster 4 or 8 port High Speed Buffered PCI
Communication Controllers
Specifications
Packages required: ppp
License required: level1
Home menu level: /interface ppp-client , /interface ppp-server
Standards and Technologies: PPP (RFC 1661)
Hardware usage: Not significant
Related Documents
• Package Management
• Device Driver List
• IP Addresses and ARP
• Log Management
• AAA
Additional Documents
• http://www.ietf.org/rfc/rfc2138.txt?number=2138
• http://www.ietf.org/rfc/rfc2138.txt?number=2139
Serial Port Configuration
Home menu level: /port
Property Description
name ( name ; default: serialN ) - port name
used-by ( read-only: text ) - shows the user of the port. Only free ports can be used in PPP setup
baud-rate ( integer ; default: 9600 ) - maximal data rate of the port
data-bits ( 7 | 8 ; default: 8 ) - number of bits per character transmitted
parity ( none | even | odd ; default: none ) - character parity check method
stop-bits ( 1 | 2 ; default: 1 ) - number of stop bits after each character transmitted
flow-control ( none | hardware | xon-xoff ; default: hardware ) - flow control method
Notes
Keep in mind that baud-rate, data-bits, parity, stop-bits and flow control parameters must be the
same for both communicating sides.
Page 229 of 695
Copyright 1999-2007, MikroTik. All rights reserved. Mikrotik, RouterOS and RouterBOARD are trademarks of Mikrotikls SIA.
Other trademarks and registred trademarks mentioned herein are properties of their respective owners.
