4-21
4
Maintenance
Replacing the filter of the cooling fan
Replace the filter of the cooling fan periodically. (Once around a month)
1
Press the to move the Y-bar to the front.
2
Turn the main power switch located on the left of the main unit off.
3
Remove the front covers on both sides of the Y-bar, and open the front covers.
• Remove the screws (4 pcs each) on the front covers, and remove the covers.
• The cooling fans are on the circled places (6 places) shown on the below. When replacing the cooling fan
filter, replace all the filters.
• When replacing, be sure to wear the supplied goggles and gloves since you may get ink in your eyes.
Articles required for
replacement works
• Gloves • Goggles • Phillips screwdriver • Filter
*1
*1. The supplied filter contains 24 sheets.
For purchase of the filter (Product No.: SPC-0528), please get in touch with your sales agent or our branch office nearest you.
