MIMAKI JFX-1631/1615 - Drawing an image from source data

2-11
2
Basic Operations
Drawing an image from source data
Starting the drawing operation
1
Set the media ( P.2-5)
(1) Open/Close the suction valve adjusting to the media size.
(2) Pressing the key, put on the VACUUM lamp.
(3) Pressing the key, absorb the media.
2
Press the key in the local mode.
• The device goes in the remote mode and data from the computer
can be received.
3
Transmit data to be drawn from the computer
• Drawing conditions are displayed.
• As for the data transmission method, see the instruction manual
of the output software.
4
Start drawing
• The drawing origin is not changed after completion of the drawing.
• If the UV irradiation device is not ready or the temperature of the water heating system has not reached
the predetermined value, a message is displayed. Drawing is not allowed in such cases. When the
display is disappeared, drawing can be started.
• Data transmission is allowed even if both errors are displayed. Drawing is started after the display is
disappeared.
VACUUM/BLOW
ON/OFF
*REMOTE*
2.5mm
REMOTE
*REMOTE* 600X600
HOST/4P/B/N 2.5mm
Resolution: 600DPI
Pass
Priority is set to “HOST” :
“HOST” is displayed.
Priority is set to “PLOT” :
Print quality (STD/FINE/FASR) is
displayed.
Direction:
“B” denotes bi-directional.
“U” denotes uni-directional.
Scanning speed:
“N” denotes normal.
“x2” denotes the
double speed.
