21 - 12 BeneVision N1 Patient Monitor Operator’s Manual
2. Select the Module tab → ECG tab.
3. From the bottom left corner of the dialog select
Calibrate.
21.5.5 Setting Parameter Measurement Timeout
NIBP measurements become outline fonts after a preset time. This feature prevents older values being
misinterpreted as current measurements. To adjust the timeout period for PAWP, and NIBP, follow this
procedure:
1. Select the
Main Menu quick key → from the System column select Maintenance → input the required
password
→ select .
2. Select the
Module tab → select Other.
3. Set the timeout period for PAWP and NIBP.
21.5.6 Setting Flow Rate (For Sidestream CO
2
Module Without O
2
)
When you are using the sidestream CO
2
module without the O
2
monitoring function to monitor a neonatal
patient, you can select flow rate. To do so, follow this procedure:
1. Ensure that the sidestream module without O
2
is inserted in the monitor.
2. Select the
Main Menu quick key → from the System column select Maintenance → input the required
password
→ select .
3. Select the
Module tab → Other tab.
4. Set
CO2 Flow Rate For Neo.
21.6 Setting the Printer
21.6.1 Setting the Printer
To set a network printer, follow this procedure:
1. Select the
Main Menu quick key → from the System column select Maintenance → input the required
password
→ select .
2. Select the
Print tab.
3. In the
Printer tab, select Connection Type to choose whether you want to output patient reports via the
print server or a network printer.
4. If you set
Connection Type to Print Server, perform the following settings:
â—† Print Server Address: select to input the printer server name or IP address.
â—† Port: select to input the printer server port. If the CMS is used as the printer server, set Port to
6603.
◆ Set the report type in the Report Type area. For more information, see section 21.6.2Setting the
Report Type
.
5. If you set
Connection Type to Printer, perform the following settings:
â—† Select Printer IP Address. Select to input the IP address of the desired network printer.
â—† Select Paper Size.
â—† Select Resolution.
After finishing configurations, you can select the
Print Test Page button to verify that the printer works properly.
21.6.2 Setting the Report Type
If the Connection Type is set to Print Server, you need to set the report type:
1. Select the
Main Menu quick key → from the System column select Maintenance → input the required
password
→ select .
2. Select the
Print tab.
