BeneVision N1 Patient Monitor Operator’s Manual A - 5
A.8 Audio Indicator
A.9 Monitor Interface Specifications
A.9.1 Interface Specifications of the Main Unit
A.9.2 Interface Specifications of the Modular Rack
A.9.3 Interface Specifications of the Dock
Speaker Give alarm tones (45 to 85 dB), reminder tones, key tones, QRS tones; support
PITCH TONE and multi-level tone modulation; alarm tones comply with IEC
60601-1-8.
DC power input connector 1
Multifunctional connector 1
Multi-pin connector 1
Communication interface 4
Infrared filter 1
Contact 2
Power switch 1
Sample line connector of the Sidestream
CO
2
1
Gas outlet 1
ECG cable connector 1
SpO
2
sensor connector 1
NIBP cuff connector 1
IBP cable connector 1
Temperature probe connector 2
Network connector 1
Equipotential grounding terminal 1
AC power input connector 1
VGA connector 1
Host monitor connector 1
USB connector 2
Multi-pin connector 1
Multi-pin connector 2
Infrared filter 1
Pogo pin
3
Contact 2
