BeneVision N1 Patient Monitor Operator’s Manual A - 3
A.4 Power Supply Specifications
A.4.1 External Power Supply Specifications
A.4.2 Battery Specifications
N1 main unit
Input voltage 12VDC (±10%)
Input current 2 A
AC Adapter
Input 100 to 240 VAC (-15%, +10%), 50/60 Hz (±3 Hz), 1.0A to 0.6A
Output 12VDC (±10%), 2.5A
Dock
Input voltage 100 to 240VAC (±10%)
Input current 0.65A to 0.35A
Frequency 50/60Hz (±3Hz)
Transport Dock
Input 100 to 240 VAC (-15%, +10%), 50/60 Hz (±3 Hz), 1.0A to 0.6A
AC waveform: sine
Output 12VDC (±10%), 2.5A
Battery type Rechargeable lithium-Ion battery
Voltage 7.56 VDC
Capacity 2500 mAh
Run time At least 8 hours when the monitor without internal CO
2
module is powered by
two new fully-charged batteries at 25°C ± 5°C with factory default screen
brightness, Wi-Fi disabled, ECG and SpO
2
cable connected, and auto NIBP
measurements at an interval of 15 minutes.
At least 3 hours when the monitor with internal CO
2
module is powered by
one new fully-charged battery at 25°C ± 5°C with factory default screen
brightness, Wi-Fi enabled, CO
2
sampling line connected, Temp, IBP, ECG and
SpO
2
cable connected, and auto NIBP measurements at an interval of 15
minutes.
Shutdown delay: at least 15 minutes after the low battery alarm first occurs.
Charge time For the monitor without internal CO
2
module:
no more than 6 hours to 90% when the monitor is off.
no more than 10 hours to 90% when the monitor is on.
For the monitor with internal CO
2
module:
no more than 3 hours to 90% when the monitor is off.
no more than 5 hours to 90% when the monitor is on.
