4 - 2 BeneVision N1 Patient Monitor Operator’s Manual
CAUTION
• Use only the specified display. Using unspecified displays may result in unexpected problems.
4.1.3 Quick keys of the independent external display
The following table displays the quick keys that are available for the independent external display.
Symbol Label Function Symbol Label Function
Alarm Reset Acknowledges the
ongoing alarms.
Screen Setup Enters the
Screen
Setup
dialog.
Alarm Pause Pauses the current alarms. Print Starts printing a real-time
report.
Audio Pause Pauses alarm tone. Standby Enters the Standby mode.
NIBP Start/
Stop
Starts an NIBP
measurement or stops the
current NIBP
measurement.
Manual Event Manually triggers and
saves an event.
NIBP Measure Enters the
NIBP
Measure
dialog.
Main menu Enters the main menu.
Alarm Setup Enters the Alarm dialog. More Shows more quick keys.
Discharge
Patient
Enters the Discharge
Patient
dialog box.
Patient
Management
Enters the Patient
Management dialog.
Review Enters the Review dialog. Parameters
Setup
Enters the Parameters
Setup dialog.
NIBP STAT Starts a five-minutes
continuous NIBP
measurement.
Stop All Stops all NIBP
measurements.
Zero IBP Starts IBP zero calibration. PAWP Enters the PAWP screen.
Venipuncture Opens the Venipuncture
dialog.
ECG Lead/Gain Enters the ECG Lead/
Gain dialog.
Remote View Opens the Remote View
screen.
Minitrends Enters the Minitrends
screen.
OxyCRG Opens the OxyCRG screen. ECG Full-
Screen
Enters the 12-lead ECG
full screen.
