12-3
12.2.2 Score Tile
The score tile is located in the main screen. By default, the scoring tile is not displayed. The
scoring tile will activate when you select a default scoring or load a scoring.
12.3 Calculating a Score
To calculate a score, follow this procedure:
1. Select the default scoring or load a scoring for the applicable patient category. Refer
to 12.6.2 Selecting Default Scoring or 12.6.4 Loading a Scoring.
2. Obtain the value of all parameters, and then total score will be automatically
calculated. Refer to 12.5 Obtaining the Total Score.
3. If necessary, record the scoring data. Refer to 12.4 Clinical Scoring Screen.
12.4 Clinical Scoring Screen
12.4.1 Score Tile in the Main Screen
The MEWS, NEWS and multi-parameter score tile display as following:
(1) Name for clinical score
(2) Total score: the background color indicates the current score level.
(3) Score level indicator
It indicates that the warning level increases from top to bottom. The current level is
enclosed in the square frame.
The IPS score tile displays as following:
(1) Name for clinical score
(1)
(2)
(3)
(1)
(2)
