12-5
(1) Icon for manual input
You need to manually input the parameter.
(2) Icon for real-time monitoring
The parameter value is from the monitor
(3) Score status for single parameter
Red : indicates that the parameter is out of the defined range.
White : indicates that the parameter is within the normal range.
(4) Recommended clinical response
In the above screens, you can:
Select [Review] to open the patient review screen. Refer to 4.4 Reviewing Patient
Data
for details.
Select [Record] to print the current patient scoring data with a recorder.
Select [Save] to save the scoring data in the [Results] screen. Refer to4.3
Manually Save Patient Data.
Select [Exit] to go to the main screen.
12.5 Obtaining the Total Score
The IPS only calculates the parameter status. The IPS does not have total score.
For other scorings, the total score will automatically be calculated when each required
(3)
(1)
(2)
(4)
