ZS3 Service Manual Page 256 of 295

Figure 19.47-ZS3

6. Locate the two screws on each bottom corner of the Dock Board. Unscrew the

higher one on each side.

7. Unscrew each of the screws in the top corners of the Dock Board. The Dock

Board is now free.

Hook

Screws
