Minebea Intec PR 5220 Series User Manual

Note:
For vehicle weighbridges:
Trucks should only be allowed to move onto the center of the weighing platform, in
order to distribute the weight evenly.
7.14.9.2 Activating the load cell
7.14.10 Corner correction
1. Select the faulty load cell and conrm, to deactivate the cell.
2. Press the [Accept] softkey.
The warning symbol replaces the weight unit.
1. After inserting and connecting the new load cell, select the line of the deactivated
load cell and conrm.
2. Press the [Accept] softkey.
A search process is started and only then is the new load cell detected.
7 Commissioning Transmitter Series PR 5220
EN-119 Minebea Intec
