Minebea Intec PR 5220 Series User Manual

Byte Name Description
6 Test
Active
Command status
7 Stand-
still
Inside
ZSR
Center
Zero
Below
Zero
Over-
load
Above
Max
ADC
error
Device status
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
The gross value (hex:000004D2 <=> 1234) can be read from bytes 03.
When the "Overload", "Test Active" or "ADC error" bits are set, the read value is invalid.
Negative values are output in the second complement.
12.2.5 Special hints for DeviceNet and EtherNet-IP
With these eldbus types, the sequence of the bytes (only applicable for words and
individual bytes) is inverted.
With long words, this problem does not arise due to compensation by the rmware.
Sequence of bytes 03, e.g.with device type and software version, see table below.
Standard sequence Sequence for DeviceNet and EtherNet-IP
Byte 0 TYPE MSB Byte 0 SUBVERSION
Byte 1 TYPE LSB Byte 1 MAIN VERSION
Byte 2 MAIN VERSION Byte 2 TYPE LSB
Byte 3 SUBVERSION Byte3 TYPE MSB
Consequently, the sequence on the PLC side must be changed when using the DeviceNet
and EtherNet–IP eld bus types.
12.2.6 Fieldbus register
12.2.6.1 Register 0: I/O status bits (read)
Dynamic status
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Input 3 Input 2 Input 1
Byte 1 Output 3 Output 2 Output 1
Byte 2 Limit 3 Limit 2 Limit 1
Byte 3
12.2.6.2 Register 1: Scale status (Read)
Dynamic status
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 OUT STND INZSR CZERO BELOW0 OVL >Max ADUERR
Byte 1 E9 E6 E1 E3 E7
Byte 2 PowerFail ActionAc-
tive
CmdError
12 Fieldbus interface Transmitter Series PR 5220
EN-197 Minebea Intec
