Example:
Contact input
If the voltage at terminals (in this example: 1-GND) is 10 V DC, input 1 is activated (true).
4.4.6 Digital outputs
Three passive opto-decoupled outputs are permanently built into the device. The
interface can be congured by software.
All outputs have a common GND (-).
Specications
Description Data
Connection Terminal, 4-pin
Qty 3 outputs
Transmitter Series PR 5220 4 Device installation
Minebea Intec EN-36
