Note:
Error messages, calibration see Chapter 16.5.
7.12.5 Determining the scale interval
The scale interval (d) is the dierence between two successive display values.
Example:
Max = 6000 kg
Scale interval (1 d) = 2 kg
Calculation for scale interval for Max (automatic):
d = Max/scale interval (1 d)
d
c
= 6000 kg/2 kg
d
c
= 3000
Procedure:
The weight unit is taken from [Max]. The number of digits behind the decimal point is
also automatically determined when [Max] is entered.
1. Enter the [Max] load with decimal places (in this example: 3000.0).
2. Press to select the weight unit.
3. Conrm entries with or .
The verication is displayed by "Setting Max…".
7 Commissioning Transmitter Series PR 5220
EN-79 Minebea Intec
