Byte 3 TareActive CalActive TestActive
Note:
Byte 0 corresponds to byte 7 in the output area; for weight error, see also the table in
Chapter 16.1.
Bit Description
ADUERR Error of analog conversion/load cell circuit (OR function of the E1,
E3, E7 bits).
>Max Gross value is higher than Max (FSD); the scale range was exceeded.
OVL Scale overload; Gross >Max + overload, Error 2
BELOW0 Gross weight is negative (<0-¼ d).
CZERO "Center of zero", weight within 0 ±¼ d.
INZSR The gross weight is within the zero setting range.
STND The scale is stable.
OUT Below zero or above Max (FSD) (0-¼ d >weight value >Max).
E7 The measuring signal is negative (inverse conversion), Error 7
E6 No or too low sense voltage; Error 6
E3 The measuring signal is >36 mV (no end of conversion), Error 3
E1 Arithmetic error (overow), Error 1
E9 No communication with xBPI scale, Error 9
CmdError Error during execution (cmdError); e.g.the "taring" operation is not
handled, because the scale is not stable. The error is stored
inLastError (register 4).
The bit is reset with the ResetError bit (register 121).
ActionActive The operation is being processed; processing is ongoing.
PowerFail Power failure; is always set after power on. The PowerFail bit is reset
with the ResetPWF bit (register 85) "Reset power failure."
TestActive The analog test is busy.
CalActive The device is/was congured.
When this bit is 1, the scale parameters (EXPO/UNIT/STEP) must be
read again.
Set after "Power on" and reset after reading the FSD.
TareActive The instrument was tared.
12.2.6.3 Register 2: State of state-controlled action bits (Read)
Signal state
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Transmitter Series PR 5220 12 Fieldbus interface
Minebea Intec EN-198
