[Measuretime]
Measuring time: The duration of a measurement can be selected.
Selection: 5 ms, 10 ms, 20 ms, 40 ms, 80 ms, 160 ms, <320 ms>, 640 ms, 960 ms,
1280 ms, 1600 ms.
[Digital lter]
Selection of the digital lter (lter characteristic): <o> (no Filter), Bessel, aperiod.
(aperiodic), Butterw. (Butterworth), Tcheby. (Tschebysche)
The following includes examples of interference signals for the dierent lter types:
Bessel lter Aperiodic lter
Butterworth lter Tschebysche lter
A digital lter can be switched on only with the measuring time set to <160 ms.
If no particularly frequent uctuations are expected in ongoing operation, the following
settings are recommended:
[Measuretime]: <160 ms
[Digital lter]: aperiod.
[Fcut]: 2.00 Hz
[Fcut]
This line only is shown if the digital lter is switched on.
The smaller the cut-o frequency, the slower the measurement and the more stable the
measurement result.
Transmitter Series PR 5220 7 Commissioning
Minebea Intec EN-92
