1.4 Understanding Hardware Features
NOTE: Depending upon the specific model purchased, the color of your device may not exactly
match the device shown in this manual.
Front Components
Ref Component Description See Also
Touch Screen
Displays the output of your device. Tap the
screen with the stylus to select menu
commands or enter information.
Mute Button
Toggles the mute on and off. Section 2.2
Moves up, down, left or right by pressing the
corresponding area of the pad.
Navigation Pad
Selects highlighted item by pressing in the
center.
Section 2.2
Back Button
Goes back to the previous screen. Section 2.2
Charge Indicator
Glows bright amber to indicate that the
battery is charging, and turns green when the
battery is fully charged.
Section 1.2
Home
Section 2.2
Navigation Settings
Chapters 5~8
Zoom In
]
Quick Buttons
Zoom Out
Section 4.3
^
Speaker
Sends out music, sounds and voice.
8
