LED Indications during Easy Replacement
The following table shows the LED indications that are used for the charger during the easy
replacement procedure.
See also Figure Update Completed while in Charger on page 79.
ATTACH THE HINGE-TYPE CLIP
Attach the hinge-type belt clip as described in the illustration below.
3 When the text "Start phone replacement?" is displayed, release .
Press "Yes" (left soft key).
The text "Follow the instructions. Each step can take several minutes." appears in the
display. Press "OK"(left soft key).
4, 5 When the text "Please insert old phone in charger" is displayed, replace the new handset
with the old handset. The handset can either be switched on or off.
NOTE: The left charging slot in the CR3 Charging Rack has to be used for both handsets.
The handset is restarted and after a few seconds, the text "Saving settings. Do not remove
phone from charger" appears. The charger LED changes to slow orange flashing. It may
take several minutes.
IMPORTANT: If the old handset cannot communicate with the charger, put the new
handset in the charger to restore its settings (that is, the handset’s IPDI). If this step
is not performed, the new handset must be sent for service. The old handset’s
settings might be transferred to the new handset by using WinPDM. refer to the
Configuration Manual for the handset; see Related Documents on page 127.
6, 7 When the text "Please insert new phone in charger" is displayed, replace the old handset
with the new handset. The text "Restoring settings" is displayed.
IMPORTANT: Do not remove the handset while the text "Restoring settings" is displayed.
8 When the text "Phone successfully replaced. Please remove phone to restart." appears
in the display, remove the handset from the charger. The handset is automatically
restarted.
LED INDICATION DESCRIPTION
Orange, flashing (1 000 ms on, 1 000 ms
off)
File transfer during Easy Replacement.
Orange, flashing (100 ms on, 800 ms off) “Change phone” indication during Easy Replacement.
Red, flashing (100 ms on, 800 ms off) Error indication during Easy Replacement. Put back
old handset in charger.
Red, flashing (900 ms on, 100 ms off) Error during Easy Replacement. Service needed for
both handsets.
