194
H
ARDWARE UPDATE
CHAPTER 6 OPERATION AND MAINTENANCE
NOTE: The microSD card must be handled very carefully. The contacts must be free from dust, humidity,
oil, etc. Do not store the card in warm areas (exposed to direct sunlight, for example). Do not bend the
card as this may damage the contacts.
1. Switch off the cordless phone.
2. Open the battery compartment and remove the battery.
3. Push the card holder downwards and carefully tilt the cover sligghtly upwards (see microSD card on
the left).
CAUTION: Never touch the now visible and shining golden contacts! Static discharges may lead to
device malfunction.
4. Place the card in the holder (with the contact surfaces downwards and the side card interfaces left-
wards).
5. Close the card holder then carefully push it upwards until it snaps into place.
6. Only for Mitel 620 DECT, Mitel 630 DECT with black card holder:
Take the protective cover provided with the card and put it on top of the card holder (see microSD
card rightwards).
NOTE: The protective cover should not be used for Mitel 620 DECT, Mitel 630 DECT with a white card
holder or in Mitel 622 DECT, Mitel 632 DECT and Mitel 650 DECT.
7. Insert the battery and cover the battery compartment.
Figure 6.3: microSD card
Behaviour after inserting a new microSD card
After starting the cordless phone you will receive, in the start phase, a message informing you that a new
card has been detected. The two typical cases are described below:
Cordless phone has not yet been registered:
Accept the new card.
• The local settings are copied to the card.
Register the phone on the communication server.
• The registration data is stored on the card.
• Modifications on the local settings are henceforth also stored on the card.
