Mitsubishi L02CPU User Manual

167
CHAPTER 3 CPU MODULE FUNCTIONS
3
3.30 CPU Module Change Function with SD Memory Card
(b) Maximum backup data size
The following shows the maximum backup data size.
(Unit: K byte)
The backup data size can be checked by the following.
• "Create Backup Data for PLC Module Change" dialog box ( Page 173, Section 3.30.1 (2)(b))
• SD698 and SD699
*1
*1 Available after starting backup.
Backup target data (drive) L02CPU L26CPU-BT
Program memory (drive 0) 82 1048
Standard RAM (drive 3) 130 770
Standard ROM (drive 4) 516 2056
Device data 128 128
System data 41 64
Total (maximum) 897 4066
