T200 User's Manual SECTION 2: SAFETY INSTRUCTIONS
PAGE 2-6
2.3.1 System Safeguards
a) General Safety Requirements
Users are required to implement safety measures with all equipment, systems and installations into which the T200
Servo-drive are installed. In addition, safeguards must be an integral part of workcell design, installation, operator
training and operator procedures where this equipment is used.
The T200 is suitable for use in a circuit capable of delivering not more than 5000 rms symmetrical amperes, 240 volts
maximum.
b) Specific Safety Requirements
The specific safety measures described below are required to be installed by the user into all equipment, systems and
installations into which the T200 Series Controllers are installed.
The user is required to provide safety interlocks to prevent unexpected restart during servicing of the T200 Series
Controller and any equipment attached to or driven by these units.
The T200 Servo-drives themselves must be installed in enclosures or cabinets that provide a degree of ingress protection
against liquids and objects of at least IP54. These enclosures or cabinets must be accessible to technically qualified
service or maintenance persons only. All external Regen ( Regenerative circuit) resistors used with the T200 must be
installed in enclosures which provide a degree of ingress protection against liquids and objects of at least IP22 and
which are accessible to technically qualified service or maintenance persons only. Protection against electric shock must
be maintained when installing these resistors.
The T200 Servo-drive must be permanently and reliably connected to Earth and all conductive parts in the IP54 rated
enclosure or cabinet must be permanently connected to Earth. The impedance between the earth terminal and any
accessible part of the enclosure or cabinet shall be less than or equal to 0.1 ohms.
All electrical supply wires and cables to this equipment must be installed in wireways (cable routings) which are smooth
and free from sharp edges.
The optional 24V input is intended for use in the secondary of a Class 2 supply. Alternatively it should be fitted with a
UL Listed Current limiting type fuse rated 3A on the supply side to the device.
Users are directed to refer to the European Union (EU) Machine Safety
Directive: 89/392/EEC (as amended by EU Directives 91/368/EEC,
93/44/EEC and 93/68/EEC) and EU Low Voltage Directive 73/23/EEC
(as amended by EU Directive 93/68/EEC) for essential health and
safety requirements to be met. Furthermore the requirements of the EU
EMC Directive: 89/336/EEC (as amended by EU Directive 92/31/EEC
and 93/68/EEC) must be met by all equipment, systems and
installations into which the T200 Power Supply and Controllers are
installed.
Users are recommended to refer to the latest publications of the
European Union (EU) Commission and to local regulations for further
information on the requirements of these Directives of the EU.
Required for
CE-Compliance
