Troubleshooting
8-12 October 2019 16K PLUS
Limiting Bed Speed
The speed of the bed can be limited by adjusting the
stops on the valve rocker. These steps are usually used
to limit the speed of the bed, but can also be used for
the grab hooks or the push off if desired.
Note: It is recommended that the grab hooks and
push off not be limited.
Note: For the hitch, Alignment Arms, Power Slide or
Loader, it is preferable to limit these functions
using the settings in the “Adjust - Speed
Adjustments” menu.
• Loosen the set-screw on the valve using a 3mm Allen
wrench.
• Adjust the stop by screwing it down (to slow the bed),
again using a 3 mm Allen wrench.
• Tighten the set screw.
Repeat the process on the other side of the rocker to
limit the valve in the other direction.
Limit Screw
Set Screw
