Symbol Identication
Hitch Position
In the top left corner of the screen a symbol indicates
the position of the hitch.
• The green indicates the hitch is inline.
• The red indicates the hitch is offset.
• The red indicates the hitch is fully offset.
Note: It is only safe to travel with hitch inline and
green check mark displayed.
Inline Partially Offset Fully Offset
Power Slide Position
In automatic mode many of the functions rely on the
power slide starting in the correct position.
• The green indicates the power slide is ready to
begin the Auto Load Sequence.
• The red indicates the power slide is out of Home
Position.
Note: See “Resetting Power Slide” for more
information on setting the power slide in the
Home Position.
Ready Out of Position
