Morris PROAG 16K PLUS - Auto Align Bale Runner Directional Conventions; Machine Conventions

Operation
16K PLUS October 2019 5-5
Machine Conventions
Auto Align Bale Runner Directional Conventions
Hitch Offset — Hitch Inline
Loader Raised — Loader Lowered
Bed Raised - Bed Lowerd
“Right and Left” The right and left side of the Bale Runner is your
right or left when standing behind the Bale Runner
and looking toward the front of the machine.
“Front and Rear” The front is the high end of the bed. The rear of the
Bale Runner is the low end of the bed.
“Raise the Bed” Move the hydraulic control to move the Bed into the
raised position.
“Lower the Bed” Move the hydraulic control to move the Bed into the
lowered position.
“Offset” The machine configuration when the Hitch is
maneuvered to allow machine to pick up bales. The
end of the Hitch is to the left of the left side tire.
“Inline” The machine conguration when the end of the Hitch
is centered between the wheels of the Bale Runner.
“Raise the Loader” Move the hydraulic control to move, or physically lift
the Loader into the raised position.
“Lower the Loader” Move the hydraulic control to move, or allow Loader
to rest in the lowered position.
